Delivery Van Loading Ramps
Rear & Side Mounted Delivery Van Loading Ramps
Delivery Business Loading Ramp Applications
|
• Computer Service & Delivery |
• Office Supply Delivery Business |
Loading Ramps for the Sprinter Van
The Handi-Ramp Sprinter Ramp is ten feet long when fully extended. It comes in two widths 36 inches and 45 inches and can handle weight capacities of 750 pounds or 1200 pounds.
Handi-Ramp® Side Mounted Delivery Van Ramp
All of the ramps in the Delivery Loading Van Ramp System Series are equipped with "assisted lifting" for ease of use. The Delivery Loading Van Ramps are all equipped with non-skid tread ways and wheel guides for added safety. The Delivery Loading Van Ramp Series includes a full range of van ramps designed to be mounted in vans or mini-vans.
Our Delivery Loading Van Ramps are available in 5 foot, 6 1/2 foot (primarily for mini-vans) and 7 foot lengths to correspond with your individual needs. The standard width of 26 inches accommodates most vehicles. Other widths are available on special order.
All of our Van Ramps are lightweight and can be operated with minimum effort by one person. Equipped with "spring assisted lifting", Handi-Ramp® Van Ramps have been designed for ease of use.
Non-skid surface and side flanges are included on all Handi-Ramp® Van Ramps offering safe and easy access to your van.
All Handi-Ramp® Van Ramps are delivered fully assembled and require a simple 3-bolt installation. Depending upon your vehicle, the ramp will mount either on the floor of your van or in the step well using three brackets. Ramps can be installed to create easy access through either a sliding side door or the rear doors.
Quick-Mount for Delivery Vans
Our new Quik-Mount(TM) mounting system allows van and RV owners to install and completely remove our van ramp in minutes when not in use.
Aluminum or Expanded Metal Van Ramps
The Handi-Ramp® Van Ramps are manufactured from either Aluminum or Expanded Metal, both have their advantages:
• The Aluminum Van Ramp, requires less lifting effort and has the best non-skid surface available.
• The Expanded Metal Van Ramp is less expensive and provides better visibility for the driver and passengers when folded up in the van.
Delivery Business Loading Van Ramps & Accessories
|
Description |
Product No. |
Capacity |
Weight |
|
Aluminum Van Ramp |
|||
| 5 ft. long | AV60 | 750lbs. | 17½ lbs. * |
| 6½ ft. long | AV78 | 750lbs. | 19½ lbs. * |
| 7 ft. long | AV84 | 750lbs. | 20 lbs. * |
|
Expanded Metal Van Ramp |
|||
| 5 ft. long | EV60 | 1,000 lbs | 30 lbs. * |
| 6½ ft. long | EV78 | 1,000 lbs | 34 lbs. * |
| 7 ft. long | EV84 | 1,000 lbs | 35 lbs. * |
| * All van ramps are equipped with "assisted lifting". The weights listed approximate lifting effort. | |||
Handi-Ramp® Quick-Mount for Vans
|
Description |
Product No. |
Weight |
| Q-Mount (Floor Mount) | QM-S | 8 lbs. |
| Q-Mount (Step Well Mount) | QM-P | 8 lbs. |
Handi-Ramp's products are available across North America including Alaska, Hawaii, Canada and Puerto Rico.
Call us toll free at (800) 876-RAMP or (847) 680-7700 to discuss your specific needs.
